Keysight Technologies MSOX2014A

Configure Unit

Available to Buy Online

View Configurations

Mixed-Signal Digital Oscilloscope; 4+8 Channels, 100 MHz

Model

MSOX2014A

Product Family

Oscilloscopes & Logic Analyzers

Manufacturer

Keysight Technologies

Configured models contain the following attributes:

Oscilloscopes & Logic AnalyzersOscilloscopes < 1GHz10MHz <= 100MHz202 GS/s

Configurations

Key Specs

Product Overview

Resources

Let us help you with your exact configuration

Please use 'Get Quick Quote' or ‘Configure Unit’ and we’ll contact you and quote for your exact need.

Configure Unit

You can also get in touch, if you prefer, and our experts will be able to guide you with the right application and procurement solution for this product.

Key Specs

Indicates attributes available at part level. See Configurations tab for part detail.

Attribute	Value
High Frequency (range)	10MHz <= 100MHz
Channel/Port Count	20
Maximum Sample/Data Rate	2 GS/s

Product Overview

The InfiniiVision 2000 X-Series offers entry-level price points to fit your budget with superior performance and optional capabilities that are not available in any other oscilloscope in its class.

Sometimes you need a basic oscilloscope with a little more functionality — features like advanced waveform math, higher updates rates, or mixed signal capabilities. All of this is available in the InfiniiVision 2000 X-Series to enable you to perform deeper analysis in an entry-level oscilloscope.

Key Features

PathWave BenchVue oscilloscope software for remote control, data logging, and automated testing

Achieve 70 MHz to 200 MHz of bandwidth

Teach your students how to use an oscilloscope with the Educator’s Oscilloscope Training Kit

View more signals at once with 8 digital channels in the mixed signal analysis option (MSO)

Simulate operations with standard advanced math functions

Isolate and analyze pulses, bursts, or infrequent glitches with segmented memory

Perform easy pass / fail analysis with mask testing

Specifications
InfiniiVision 2000 X-Series Oscilloscopes
Model Overview
Model	2002A	2004A	2012A	2014A	2022A	2024A
Bandwidth* (–3 dB)	70 MHz	70 MHz	100 MHz	100 MHz	200 MHz	200 MHz
Calculated Rise Time (10 to 90%)	≤ 5 ns	≤ 5 ns	≤ 3.5 ns	≤ 3.5 ns	≤ 1.75 ns	≤ 1.75 ns
Input Channels DSOX MSOX	2 2 + 8	4 4 + 8	2 2 + 8	4 4 + 8	2 2 + 8	4 4 + 8
Maximum Sample Rate*	2 GSa/s half-channel interleaved, 1 GSa/s per channel	2 GSa/s half-channel interleaved, 1 GSa/s per channel	2 GSa/s half-channel interleaved, 1 GSa/s per channel	2 GSa/s half-channel interleaved, 1 GSa/s per channel	2 GSa/s half-channel interleaved, 1 GSa/s per channel	2 GSa/s half-channel interleaved, 1 GSa/s per channel
Maximum Memory Depth	1M points per channel (standard)	1M points per channel (standard)	1M points per channel (standard)	1M points per channel (standard)	1M points per channel (standard)	1M points per channel (standard)
Display Size and Type	8.5-inch WVGA with 64 levels of intensity grading	8.5-inch WVGA with 64 levels of intensity grading	8.5-inch WVGA with 64 levels of intensity grading	8.5-inch WVGA with 64 levels of intensity grading	8.5-inch WVGA with 64 levels of intensity grading	8.5-inch WVGA with 64 levels of intensity grading
Waveform Update Rate	200,000 waveforms per second	200,000 waveforms per second	200,000 waveforms per second	200,000 waveforms per second	200,000 waveforms per second	200,000 waveforms per second

Note:

* Denotes warranted specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and from ± 10 °C firmware calibration temperature.

Specifications
InfiniiVision X-Series Oscilloscopes
Series Overview
X-Series	InfiniiVision 1000 X-Series	InfiniiVision 2000 X-Series	InfiniiVision 3000T X-Series	InfiniiVision 4000 X-Series
Analog Channels	2 and 4	2 and 4	2 and 4	2 and 4
Bandwidth (upgradable)	50MHz 70MHz 100MHz 200MHz	70MHz 100MHz 200MHz	100MHz 200MHz 350MHz 500MHz 1 GHz	200MHz 350MHz 500MHz 1 GHz 1.5 GHz
Digital Channels	External trigger can be used as a 3rd digital channel for 2 channel model	8 (MSO models or upgrade) *	16 (MSO models or upgrade)	16 (MSO models or upgrade)
Maximum Sample Rate	2 GSa/s	2 GSa/s	5 GSa/s	5 GSa/s
Maximum Memory Depth	Up to 2 Mpts standard	1 Mpt/channel	4 Mpts	4 Mpts
Waveform Update Rate	Up to 200,000 wfms/sec	> 200,000 wfms/sec	> 1,000,000 wfms/sec	> 1,000,000 wfms/sec
Display	7-inch display	8.5-inch display	8.5-inch capacitive touch display	12.1-inch capacitive touch display
Zone Touch Trigger	No	No	Standard	Standard
WaveGen 20-MHz Function/ Arbitrary Waveform Generator	Single-channel function only (standard on G models)	Single-channel function only (option)	Single-channel AWG (option)	Dual-channel AWG (option)
Integrated Digital Voltmeter (standard)	Yes	Yes	Yes	Yes
Integrated Hardware Counter (standard)	5-digits	5-digits	5-digits 8-digits - totalizer	5-digits
Serial Protocol Analysis	I²C, UART (standard on all models) SPI, CAN/LIN (standard on DSO models)	Yes (optional: CAN, LIN, I²C, SPI, RS232/UART) *	Yes (optional: ARINC 429 CAN/CANdbc/CAN-FD/LIN/LIN symbolic SENT FlexRay I²C I²S LIN MIL-STD-1553 SPI UART/RS232 CXPI Manchester/NRZ)	Yes (optional: ARINC 429 CAN/CAN-dbc/CANFD/LIN/LIN symbolic SENT FlexRay I²C I²S LIN MIL-STD-1553 SPI UART/RS232 USB 2.0, CXPI Manchester/NRZ)
Segmented Memory	Yes (standard on DSO model)	Standard	Standard	Standard
Mask/Limit Testing	Yes (standard on DSO model)	Yes (option)	Yes (option)	Yes (option)
Power Analysis	No	No	Yes (option)	Yes (option)
USB 2.0 Signal Quality Test	No	No	No	Yes (option)
HDTV Analysis	No	No	Yes (option)	Yes (option)
Advanced Waveform Math	No	Standard	Standard	Standard
Connectivity	Standard USB 2.0 LAN	Standard USB 2.0 (LAN/video option) (GPIB option)	Standard USB 2.0 (LAN/video option) (GPIB option)	Standard USB2.0 LAN video out (GPIB option)

Note:

* The digital channels and serial protocol analysis cannot be used simultaneously on 2000 X-Series.
