Rohde & Schwarz ESR26 (1316.3003.26)

EMI Test Receiver; 9 kHz to 26.5 GHz

型號

ESR26 (1316.3003.26)

產品類別

RF & Microwave Network Analyzers

製造商

Rohde & Schwarz

配置型號包含以下特性:

RF & Microwave Network AnalyzersEMC / EMI / RFI Analyzers20GHz <= 50GHz1kHz <= 100kHz

配置

技术指标

產品總覽

資源

讓我們為您提供準確的配置

請使用“獲取快速報價”，我們將根據您的需求與您聯繫並報價。

您也可以選擇保持聯繫，我們會為您提供正確的應用和採購解決方案。

技术指标

在選擇附件時標明其特性，有關附件詳細資訊請參見“配置”選項。

特性	參數
High Frequency (range)	20GHz <= 50GHz
Low Frequency (range)	1kHz <= 100kHz

產品總覽

The ESR is an EMI test receiver build to measure electromagnetic disturbances using conventional stepped scans or ultrafast FFT based time domain scans. It also functions as a powerful signal and spectrum analyzer. The receiver features real-time spectrum analysis with a wide range of diagnostic tools for detailed analysis of disturbance signals and their history. With these tools, users can detect hidden or sporadic emissions and analyze their causes.

The ESR comes with intuitive menus on an easy to use touchscreen. Compact dimensions, low weight, optional ruggedized housing and optional DC power supply make the R&S®ESR an ideal choice also for mobile applications.

Key Features

Frequency ranges from 10 Hz to 3, 7 or 26.5 GHz

In line with CISPR 16-1-1, ANSI C63.2, MIL‑STD‑461 and FCC standards

High dynamic range and accuracy

Ultrafast measurements with FFT based time domain scan

Real-time spectrum analysis with 40 MHz bandwidth (option)

Specifications
ESR / EMI Test Receiver
Model Overview
Model	Order Number	Frequency Range	Measurement Bandwidth	Noise Indication	1db Compression Nominal @ 1 GHz	Residual Spurious Responses (1 MHz ≤ f ≤ 1 GHz)
ESR3	1316.3003.03	9 kHz to 3.6 GHz (optional 10 Hz)	10 Hz to 10 MHz 40 MHz in zerospan	< -7 dBµV	+10 dBm	< -103 dBm
ESR7	1316.3003.07	9 kHz to 7 GHz (optional 10 Hz)	10 Hz to 10 MHz 40 MHz in zerospan	< -7 dBµV	+10 dBm	< -103 dBm
ESR26	1316.3003.26	9 kHz to 26.5 GHz (optional 10 Hz)	10 Hz to 10 MHz 40 MHz in zerospan	< -5 dBµV	+10 dBm	< -103 dBm

Specifications
EMI Test Receiver
Model Overview
Model	Order Number	Description
ESR3	1316.3003.03	EMI Test Receiver
ESR7	1316.3003.07	EMI Test Receiver
ESR26	1316.3003.26	EMI Test Receiver
Options
ESR-B1	1316.4100.02	Impact Protection Retrofittable: Yes Remarks: User-Retrofittable
FSV-B4	1310.9522.02	OCXO Reference Frequency Retrofittable: Yes Remarks: User-Retrofittable
FSV-B4	1310.9522.03	OCXO Extended Frequency Stability Retrofittable: Yes Remarks: User-Retrofittable
FSV-B9	1310.9545.02	Tracking Generator (9 kHz to 7 GHz) Retrofittable: Yes Remarks: Retrofit in Service Center
ESR-B10	1310.9551.03	External Generator Control Retrofittable: Yes Remarks: Retrofit in Service Center
ESR-B18	1316.3555.18	Solid State Drive (SSD, removable hard drive) Retrofittable: Yes Remarks: User-Retrofittable
ESR-B19	1316.3561.18	Spare Hard Drive (removable hard drive) Retrofittable: Yes Remarks: User-Retrofittable
FSV-B22	1310.9600.02	RF Preamplifier (100 kHz to 7 GHz) Retrofittable: Yes Remarks: User-Retrofittable for ESR3 and ESR7 Only
ESR-B29	1316.3578.02	Frequency Extension 10 Hz and MIL bandwidths Retrofittable: Yes Remarks: User-Retrofittable
FSV-B30	1329.0243.02	DC Power Supply for 12 V/24 V supply voltage Retrofittable: Yes Remarks: User-Retrofittable
FSV-B32	1321.3750.04	Lithium-Ion Battery Pack Retrofittable: Yes Remarks: User-Retrofittable, requires FSV-B30 and FSV-B34
FSV-B34	1321.3950.02	Lithium-Ion Battery Charger
ESR-B50	1316.3584.02	Hardware for Time Domain and Real-Time Analysis Retrofittable: Yes Remarks: Retrofit in Service Center
Firmware/Software
ESR-K53	1316.3590.02	Time Domain Scan Remarks: Requires ESR-B50
ESR-K55	1316.3603.02	Real-Time Analysis Remarks: Requires ESR-B50
ESR-K56	1316.3610.02	IF Analysis
