One field-optimized, powerful test solution. And the industry’s smallest and most comprehensive 10G handheld tester.
An all-in-one Ethernet/optical solution for field technicians who install, test and troubleshoot wired, wireless, C-RAN, FTTx, fronthaul, backhaul, small cell, DAS, CWDM and data center networks.
Benefits | |
Platform Highlights | Windows 10 IoT (bring your own device, install what you want) Ultra-bright 8-inch multitouch screen Built-in connectivity—choose between Gigabit interface, WiFi, Bluetooth and 3G or 4G LTE via USB dongle Lightweight and portable solution designed for fi eld engineers or cell technicians who install, troubleshoot and maintain wired and wireless networks |
Multiservice Testing | Dual-port testing up to 10G iSAM ultra-simple multiservice activation 10G multisession transmission-control-protocol (TCP) testing with bidirectional RFC 6349 Power-over-Ethernet validation within cable test EtherSAM, RFC 2544, traffi c generation and monitoring, EtherBERT, Through Mode, TCP throughput and Smart Loopback Packet synchronization including IEEE 1588 V2 precision time protocol (PTP) and SyncE Packet capture and advanced fi ltering up to 10G Fibre Channel 1x, 2x, 4x, 8x, 10x support OTN testing OTU-1/2, OTU-1e/2e Optical SONET and SDH testing up to 10G Electrical SONET and SDH testing DSn and PDH testing including ISDN PRI iOptics—intelligent pluggable optics test application for fast validation of an optical device, with minimal configuration |
Optical Testing | Integrated tool combining an OTDR, inspection probe, visual fault locator, broadband power meter and a CW source mode iOLM-ready: intelligent multiple acquisitions at multiple wavelengths with clear go/no-go results presented in a straightforward visual format iOLM minimizes training and avoids misconfi guration thanks to automatic parameter settings 100% automated, one-step connector inspection process Completely wireless, self-powered inspection probe for connector endface inspection 18 CWDM channels or C-Band ITU DWDM grid channels 17-62 from single OTDR port for single-ended construction, in-service testing and troubleshooting through MUX/ DEMUX/OADM |
Fronthaul/FTTA/C-RAN Testing | CPRI layer-2 link validation for BBU or RRH from 1.2G to 9.8G OBSAI layer-2 link validation for BBU or RRH from 1.5G to 6.1G CPRI/OBSAI framed and unframed BER with pseudo-random bit sequence (PRBS) patterns and latency measurements CPRI/OBSAI service disruption time (SDT) measurements BBU emulation allowing RF level validation of RRHs , RET status and control and remote SFP identification Wander time error testing |
RF Spectrum Analysis | Real-time high-resolution RF spectrum analysis over CPRI |
Specifications | |
FTB-700G V2 Series | |
Series Overview | |
Model | Description |
Model (FTB-7XXG-XX) | |
FTB-720GV2-SM1 | OTDR 1310 nm/1550 nm |
FTB-720GV2-Q1-Quad | OTDR 850 nm/1300 nm, 1310 nm/1550 nm |
FTB-730GV2-SM1 | OTDR 1310 nm/1550 nm |
FTB-730GV2-SM2 | OTDR 1310/1550 nm, and 1625 nm live port |
FTB-730GV2-SM8 | OTDR 1310/1550 nm, and 1650 nm live port |
Model Options (FTB-7XXG-XX-XX) | |
Optical | Optical only (without Ethernet) |
Ethernet | Enables 10M to 1000M Electrical and GigE |
Combo | Enables Optical and Ethernet 10M to 1000M Electrical and GigE |
Base Software Options ¹ (FTB-7XXG-XX-XX-XX) | |
OTDR | Enables the OTDR application only |
iOLM | Enables the iOLM application only |
Oi | Enables iOLM and OTDR applications |
iOLM Software Options ² (FTB-7XXG-XX-XX-XX-XX) | |
00 | iOLM Standard |
iADV | iOLM Advanced ¹ |
iPRO | iOLM Pro ¹ |
Multimode Connector ³ (FTB-7XXG-XX-XX-XX-XX-XX) | |
EI-EUI-28 | UPC/DIN 47256 |
EI-EUI-89 | UPC/FC narrow key |
EI-EUI-90 | UPC/ST |
EI-EUI-91 | UPC/SC |
EI-EUI-95 | UPC/E-2000 |
EI-EUI-98 | UPC/LC |
Singlemode Connector (FTB-7XXG-XX-XX-XX-XX-XX-XX) | |
EA-EUI-28 | APC/DIN 47256 |
EA-EUI-89 | APC/FC narrow key |
EA-EUI-91 | APC/SC |
EA-EUI-95 | APC/E-2000 |
EA-EUI-98 | APC/LC |
Transport Base Options ⁴ (FTB-7XXG-XX-XX-XX-XX-XX-XX-XX) | |
SONET | SONET testing |
SDH | SDH testing |
SONET-SDH | SONET and SDH testing |
Notes:
¹ Available if Optical or Combo model option is selected.
² Available for iOLM software only.
³ Available for model FTB-720G V2-Q1-Quad only.
⁴ Available if Ethernet or combo option is selected.
