Hioki 8215

Super Megohmmeter

Model

8215

Product Family

Electrical & Power Quality

Manufacturer

Hioki

Configured models contain the following attributes:

Electrical & Power QualityInsulation / Ground Testing

Configurations

Key Specs

Product Overview

Resources

Choose your configuration

Show:

Search & combine Options e.g 'C4000; M400'

Available Options for Hioki 8215

No Configurations Found

Showing 1 - 1 of 1 results

SM-8215 SUPER MEGOHMMETER 1kV

Product ID: P-135685

Rent

Availability confirmed on quote

Quote

Quantity

No. weeks

Start date

Buy Used

Availability confirmed on quote

Enquire

Email +32 15 740 800

Source New

Enquire about our range of financial solutions

Showing 1 - 1 of 1 results

* Prices & availability are subject to change without notice. All prices may vary due to shipping terms, VAT or sales tax, import duties, and exchange rates. Products may not be available in all locations. Any listed savings are based on the full list price of new instruments and are indicative depending on date of list; actual savings may vary based on option(s), configuration, currency exchange rates, and other factors. Warranty may vary by category or specific available product. All terms to be confirmed by full written quote or available to review in the Payment page when you buy online.

¹ For Certified Pre-Owned equipment, units go into 23-step certification checks before shipping and we will confirm timescales.

Product Overview

The SM-8200 Digital Super Megohmmeter series are insulation resistance meters consisting of a constant voltage power supply and a high sensitivity current measuring element, and are designed to measure the electrical resistance of insulation materials with high insulating properties.

Key Features

Easy-to-read digital numeric and virtual analog LCD

Timer, comparator, remote start, Interlock(HV-EN) and RS-232C functions included as standard features

Functions expandable by options

A broad selection of electrodes support measuring a wide variety of objects

Specifications
Super Megohmmeter
Model Overview
Model	Measurement Voltage and Measurement Range	SM-8213	SM-8215	SM-8220
	5 V	2.5 ×10^4 - 1 ×10^11 Ω	--	--
	10 V	5 ×10^4 - 2 ×10^11 Ω	--	5 ×10^4 - 2 ×10^14 Ω
	15 V	7.5 ×10^4 - 3 ×10^11 Ω	--	--
	25 V	1.25 ×10^5 - 5 ×10^11 Ω	--	1.25 ×10^5 - 5 ×10^14 Ω
	50 V	2.5 ×10^5 - 1 ×10^12 Ω	2.5 ×10^5 - 1 ×10^12 Ω	2.5 ×10^5 - 1 ×10^15 Ω
	100 V	5 ×10^5 - 2 ×10^12 Ω	5 ×10^5 - 2 ×10^12 Ω	5 ×10^5 - 2 ×10^15 Ω
	250 V		1.25 ×10^6 - 5 ×10^12 Ω	1.25 ×10^6 - 5 ×10^15 Ω
	500 V		2.5 ×10^6 - 1 ×10^13 Ω	2.5 ×10^6 - 1 ×10^16 Ω
	1000 V		5 ×10^6 - 2 ×10^13 Ω	5 ×10^6 - 2 ×10^16 Ω

8220

Specifications
Super Megohmmeter
Model Overview
Model	SM-8213	SM-8215	SM-8220
Measuring Voltage Accuracy	±10 % (within 10 times range of min. value on each range at 20°C ), but ± 20 % at 10^8 range of the SM-8220	±10 % (within 10 times range of min. value on each range at 20°C ), but ± 20 % at 10^8 range of the SM-8220	±10 % (within 10 times range of min. value on each range at 20°C ), but ± 20 % at 10^8 range of the SM-8220
Output Current	Max. 50 mA	Max. 2 mA	Max. 2 mA
Display Type	LCD (digital & analog display)	LCD (digital & analog display)	LCD (digital & analog display)
Standard Features	Timer (1 to 999s), Comparator, Remote start, HV-EN (inter lock)	Timer (1 to 999s), Comparator, Remote start, HV-EN (inter lock)	Timer (1 to 999s), Comparator, Remote start, HV-EN (inter lock)
Interfaces	RS-232C Comparator output (open-collector)	RS-232C Comparator output (open-collector)	RS-232C Comparator output (open-collector)
Supply Voltage	Selectable 100, 120, 220 or 240 V AC ±10% 50/60 Hz 25 VA	Selectable 100, 120, 220 or 240 V AC ±10% 50/60 Hz 25 VA	Selectable 100, 120, 220 or 240 V AC ±10% 50/60 Hz 25 VA
Dimensions W x H x D	284 mm × 139 mm × 215 mm 11.18 in x 5.47 in x 8.46 in	284 mm × 139 mm × 215 mm 11.18 in x 5.47 in x 8.46 in	284 mm × 139 mm × 215 mm 11.18 in x 5.47 in x 8.46 in
Weight	4.3 kg 151.7 oz	4.3 kg 151.7 oz	4.3 kg 151.7 oz

Specifications
Super Megohmmeter
Model Overview
Model	Description
SM-8213	The SM-8213 is ideal for insulation measurements of modern low-voltage electronic components. Easy-to-see simultaneous digital numeric and analog graduated scale displays. The maximum 50 mA current capability, which is the highest in this series, provides stable measurements of even high-value capacitors. To support measurement by computer, communication functions via RS-232C are included as a standard feature.
SM-8215	The SM-8215 is a basic insulation meter that carries on our company’s tradition of ultra-high insulation meters. It is used in various fields including electronic components and materials, and for insulation measurements on completed electrical products. The liquid crystal display includes both easy-toread digital and intuitive analog level indicators. Convenient standard features include timer, comparator, remote start and Interlock(HV-EN) functions. Measures time characteristic and voltage characteristic of insulators. To support measurement by computer, communication functions via RS-232C are included as a standard feature.
SM-8220	The SM-8220 is a top-of-the-line super megohmmeter that can measure up to 2 × 1016 Ω (at 1000 V). The combined digital and analog display is the latest evolutionary step combining our line of super megohmmeters with the newest technology. This powerful super megohmmeter handles a variety of insulation measurements, from those requiring low to high measurement voltages and measuring from low to ultra-high resistance. Convenient standard features include timer, comparator, remote start and Interlock(HV-EN) functions. These enable safer and more reliable measurement of volume and surface resistivity using flat sample text fixtures (such as the SME-8310). RS-232C communication functions required for measurement by computer are included as a standard feature
