Option	Description
E3600A-100	Test lead kit, banana plug to SMT grabber
E3630A-0E3	AC 230V single-phase 3-wire. 230 VAC +/- 23V operation, 47 to 63 Hz
E3630A-0E9	AC 100V single-phase 3-wire. 100 VAC +/- 10V operation, 47 to 63 Hz
E3630A-0EM	AC 115V single-phase 3-wire. 115 VAC +/- 11V operation, 47 to 63 Hz
E3630A-900	Power cord - United Kingdom
E3630A-901	Power cord - Australia and New Zealand
E3630A-902	Power cord - Continental Europe
E3630A-903	Power cord - United States and Canada -120V
E3630A-904	Power cord - United States and Canada -240V
E3630A-906	Power cord - Switzerland
E3630A-912	Power cord - Denmark
E3630A-917	Power cord - India
E3630A-918	Power cord - Japan - 100V
E3630A-919	Power cord - Israel
E3630A-920	Power cord - Argentina
E3630A-921	Power cord - Chile
E3630A-922	Power cord - China - 250V
E3630A-923	Power cord - South Africa
E3630A-927	Power cord - Thailand and Philippines
E3630A-930	Power cord - Brazil
E3630A-931	Power cord - Taiwan
E3630A-932	Power cord - Cambodia
E3630A-PLG	Power cord - Continental European, only for EU distributor with multiple power cord standards
E3630A-UK6	Commercial calibration certificate with test data included
E3630A-UK6H	Combination of materials for UK6
R-50C-011-3	Calibration Assurance Plan - Return to Keysight - 3 years
R-50C-011-5	Calibration Assurance Plan - Return to Keysight - 5 years
R-50C-021-3	ANSI Z540-1-1994 Calibration - 3 years
R-50C-021-5	ANSI Z540-1-1994 Calibration - 5 years
R-51B-001-5Z	Warranty Assurance Plan - Return to Keysight - 5 years
W4100-3MW	Warranty, 3mth for included accessories
W4100-FLY	Flyer, PowerPlus promotion

Attribute	Value
Maximum Voltage	20V
Maximum Current	0.5A
Maximum Power	10W
Channel/Port Count	3

Product Overview

Reliable power in dual and triple output adjustable power supply with a compact design, the E3620A, and E3630A power supplies provide excellent performance while saving space on your bench.

Keysight basic DC power supplies offer essential features for a tight budget. The multiple output, 35-50 W, E3620A and E3630A provide dual and triple outputs; small, compact size for bench use; low-noise and excellent regulation; and overload indicator to monitor output. The Keysight 35W, triple output E3630A has three versatile outputs for benchtop applications; and is offers stable and reliable power plus essential features for manual testing.

With multiple outputs in a compact unit, the E3620A and E3630A power supplies provide excellent performance while saving space on your bench. Both instruments feature a tight 0.01% line and load regulation and a low normal mode noise specification to ensure clean power for precision circuitry. Additionally, the E3620A and E3630A feature separate digital panel meters so you can monitor voltage and current simultaneously.

Key Features

Low output noise with ripple and noise <350 μVrms

Stable output, load regulation < 0.01%

Meter accuracy 0.5%

Smooth turn-on and turn-off without power spikes

Outputs protected from short-circuit damage

Common mode current less than 1 μA

Simple front panel control

Specifications
E3630A DC Power Supply
Feature	Parameter
Output Ratings (Maximum current is derated 3.3% per °C from 40°C to 55°C)	Output 1: 0 to 6 V, 0 to 2.5 A Output 2: 0 to +20 V, 0 to 0.5 A Output 3: 0 to -20 V, 0 to 0.5 A Power (max): 35 W
Ripple & Noise from 20 Hz to 20 MHz	Normal Mode Voltage rms: 350 µV Peak-to-Peak: 1.5 mV
Load & Line Regulation	0.01% + 2mV
Meter Resolution	Voltage: 10 mV Current: 10 mA

Specifications
DC Power Supply
Model Overview
Model	Description
E3620A (dual-output power supply)	The 50-watt E3620A dual-output power supply provides two 0 V to 25 Vdc outputs with the maximum current of 1 A to satisfy most bench requirements. The outputs are completely independent and isolated.
E3630A (triple-output power supply with auto-tracking feature)	The 35-watt E3630A triple-output power supply provides three DC outputs: 0 to 6 V with a maximum current of 1 to 2.5 A and 0 to 20 V and 0 to %20 V with a maximum current of 0.5 A. An auto-tracking feature lets you use one voltage control to adjust the +20 V and %20 V outputs simultaneously. The outputs track each other to within 1 percent, making it easy to adjust the power supply for circuits requiring balanced voltages.
