Flann Series 093 TFTM Waveguide to Coax Adaptors.jpg

400 819 2800需要帮忙？请与我们的专家联系

Flann 23093-TF30

Waveguide to Coax Adapter; 33.0 - 50.1 GHz

型号

23093-TF30

产品类别

RF & Microwave Power

制造商

Flann

配置型号包含以下特性:

RF & Microwave PowerNoise & OtherMicrowave Accessories

配置

技术指标

产品总览

资源

让我们为您提供准确的配置

请使用“获取快速报价”，我们将根据您的需求与您联系并报价。

您也可以选择保持联系，我们会为您提供正确的应用和采购解决方案。

产品总览

The Series 093-TF/TM Waveguide to Coax Adaptors feature an improved mechanical design offering greater durability and reliability. The Adaptors are fitted with 2.4 mm male or female coaxial connectors which are suitable for operation over full waveguide bands up to 50 GHz. Models optimized for limited and narrowband applications are also available to special order. Full details on request.

Key Features

Male and Female Connectors Available

Models up to 50 GHz

Full Band & Narrow Band Models

Specifications
Waveguide to Coax Adapter
Model	Frequency Range (GHz)	Waveguide (WG)	Waveguide (R)	Waveguide (WR)	VSWR (better than)
19093-TF30	14.5 - 22.0	19	180	51	1.25
19093-TM30	14.5 - 22.0	19	180	51	1.25
20093-TF30	17.6 - 26.7	20	220	42	1.2
20093-TM30	17.6 - 26.7	20	220	42	1.2
21093-TF30	21.7 - 33.0	21	260	34	1.25
21093-TM30	21.7 - 33.0	21	260	34	1.25
22093-TF30	26.4 - 40.1	22	320	28	1.25
22093-TM30	26.4 - 40.1	22	320	28	1.25
23093-TF30	33.0 - 50.1	23	400	22	1.4
23093-TM30	33.0 - 50.1	23	400	22	1.4
23093-TF31	40.0 - 50.0	23	400	22	1.2
23093-TM31	40.0 - 50.0	23	400	22	1.2
