The R&S®FSV-K30 option expands the R&S®FSV or R&S®FSVA signal and spectrum analyzer by adding measurement functionality otherwise only provided by special noise measurement analyzers.
The following parameters can be measured at a specified frequency or in a selectable frequency range:
- Noise figure in dB
- Noise temperature in K
- Gain in dB
The R&S®FSV-K30 can perform a wider variety of RF measurements than is possible with conventional noise measurement systems. The R&S®FSV and R&S®FSVA support the measurement of harmonics, intermodulation, spurious responses and many other RF-relevant criteria (for measurements on amplifiers and on frequency-converting DUTs, e.g. lownoise converters).
- Noise measurements
- Measurement range 0 dB to 35 dB
- Resolution 0.01 dB
- Device measurement uncertainty 0.05 dB
- Gain measurements
- Measurement range –20 dB to +60 dB
- Resolution 0.01 dB
- Measurement accuracy ±0.2 dB
